Multigas detector MSA ALTAIR 5X

Multi-gas detector MSA ALTAIR 5X can be equipped with sensors for up to six different gases. Illuminated color LCD display (optional monochrome screen), simple menu system and three buttons provide simple and logical handling. As extra security, there is "Motion Alert" which alerts if the user is immobile for too long and the "Instant Alert" function which gives the possibility to activate the alarm with the push of a button. Alarm indication occurs with a powerful (95 dB) siren, intense flashing light and vibration. Also alarms if the hygienic limit values ​​are exceeded for the toxic gases. The device stores more than 200 hours of measurement values ​​and 1000 alarm events. Can display measurement values ​​for toxic gases in units of ppm or mg/m3.

Altair 5X comes complete with built-in pump, charger, belt clip and calibration adapter.

Operating time: >18 hours (Charges in approx. 6 hours)

Dimensions / Weight: 169 x 89 x 42 mm (H x B x D) / 453 gram

Protection enclosure: IP 65 (third-party certified)

Classifications: ATEX II 2G EEx ia d II C T4

Operating temp: -20 ºC to +50 ºC

Data log: 200 hours at 1 min intervals

Standard warranty: 3 years incl. CO/H2S/LEL/O2/SO2/IR sensors. NH3 and CL2 have 2 years, others 1 year.

Examples of measurement ranges:

• Flammable gases 0 – 100% LEL (pentane as standard)
• Oxygen 0 – 30 vol %
• CO 0 – 2000 ppm
• H₂S 0 – 200 ppm
• SO2 0 – 20 ppm
• Cl2 0 – 20 ppm
• NH3 0 – 100ppm
• NO2 0 – 20 ppm
• ClO2 0 – 1 ppm
• PH3 0 – 5 ppm
• HCN 0 – 30 ppm
• CO2 0 – 10 vol%
• Butane C4H10 0 – 25 vol%
• Methane CH4 0 – 100 vol%
• Propane C3H8 0 – 100 vol%

Various accessories:

• Communication program for PC "MSA Link" (10088099)
• Car charger Altair 5x, incl. charging stand (10099397)
• IR eye with USB connection for PC, Jeteye (1001867)
• Strap
• Leather bag
