Description
Multigas detector GMI PS 500
Note only the basic unit for multi-gas detectors, measuring cells are equipped according to specification.
Dimensions / Weight: 140 x 85 x 45 mm / 395 g
Protection enclosure: IP 65/54
Classifications: ATEX II 2 G EEx iad IIC T3, MED (Wheelmark) – EC Type Approval Certificate, EN61779 (flame), EN50104 (oxygen) and EN545544 (toxic)
Logging: timed 24 hours clocked logs 1 log per minute, session minimum 180 logs, calibration minimum 8 calibration logs
Operating time
NiMH: minimum 12 hours without pump
With 3 R6 dry batteries: minimum 12 hours without pump
Sensors
- 0–100%LEL Methane, Propane, Butane, Pentane and Hydrogen
- 0–100%LEL unfiltered cell
- 0-100%LEL filtered against H2 and CH4
- Oxygen 0–25 vol%
- 0-100 ppm H2S
- 0–1000 ppm CO
- comb. H2S / CO
- 0–30 ppm SO2
- 0–100 ppm SO2
- 0–10 ppm Cl2
- 0–20 ppm NO2
- 0–100 ppm NH3
- 0–300 ppm NO
- 0–5 vol% CO2
- 0-100 or 0-1000ppm VOC
- 0–100 ppm PH3
- 0–20 ppm C6H6 Benzene
| Characteristics | ATEX, Display, Electrochemical, IR, Catalytic, MED, Pump |
|---|---|
| Gases | Oxygen O2, Explosive gases, Toxic gases, Ammonia NH3, Benzene C6H6, Butane C4H10, Phosphine PH3, Chlorine Cl2, Carbon dioxide CO2, Carbon monoxide CO, Nitrogen dioxide NO2, Nitrogen monoxide NO, Methane CH4, Pentane C5H10, Propane C3H8, Sulfur dioxide SO2, Hydrogen sulfide H2S , VOC volatile organic compounds, Hydrogen H2 |
Download
Product sheet PS500
